EROS B

View Examples of EROS B Satellite Imagery

Click on the expand button for a larger view of each image. You can also right-click and save any of the examples to your computer for a full resolution view.

Overview & HistoryEROS B SpecificationsPricing

The second panchromatic satellite owned by ImageSat International, EROS B was launched into orbit on April 25, 2006 from Svobodny Launch Complex, Russia. This high resolution satellite orbits the Earth at a height between 516 and 524 kilometers (km), collecting black and white imagery with an average resolution of 70 centimeters (cm). EROS B is the only high resolution satellite that can be tasked to collect nighttime imagery. This data has a wide array of uses including urban sprawl measurements, light pollution detection and population estimates.

Launch Details
  • Launch Date: April 25,2006, 17:03 UTC
  • Vehicle: Start-1
  • Site: Svobodny Launch Complex, Russia
  • Expected Mission Life: at least 2022
EROS B Components
  • Dimensions: 2.3-m (height) x 1.2-m (diameter), 290 kg at launch
  • Control Systems:
    • 3-axis stabilized
    • Actuators: four reaction wheels
    • Altitude determination: horizon sensors, sun sensors, star sensor, gyros and magnetometer
  • Ground Communication Systems:
    • Imagery downlink – 280 Mbit/s, X-band
    • Maintenance & metadata downlink – 2.5 or 15 kbit/s, S-band
    • Tasking & commands uplink – 2.5 or 15 kbit/s, S-band
  • Focal Plane: CCD asynchronous or synchronous pushbroom scanner, 10,380 pixels per line, 96 line arrays
  • Optical Sensor Assembly: 8-m focal length, 50-cm aperture
Orbit Characteristics
  • Altitude: 520 km ± 4 km
  • Period: 95 minutes
  • Speed:
    • In orbit – 7.6 km per second
    • Over ground – 7.0 km per second
  • Inclination: 97.4°
  • Direction: sun-synchronous circular, north to south (across the lit side of Earth)
  • Equatorial Crossing Time: 1:30 PM local time (approximate; across lit side of Earth); 12:30 AM local time (approximate; nighttime collections only)
  • Revisit Frequency: (at 45° lat)
    • 3 days (30° off-nadir)
    • 6 days (15° off-nadir)
Imaging System
  • Spectral Band: panchromatic
  • Sensor Resolution: 0.70-m (at nadir, from 520 km)
  • Spectral Band Wavelength Range: (in nm)
    • Panchromatic – 500 to 900
  • Sunlight Conditions: no limitation
  • Dynamic Range: 10-bits
Collection Capabilities
  • Footprint Width: 7 km (at nadir, from 520 km)
  • Maximum Collection Geometry: (at 30° off-nadir)
    • Mono, large area – 25 km x 40 km (6 strips wide)
    • Mono, long strip – 250 km x 7 km (1 strip only)
    • Stereo, large area – 25 km x 20 km (3 pairs wide)
  • Onboard Storage Capacity: 30 7×7 km scenes
  • Georeferenced Horizontal Accuracy: < 9m CE90 relative (within scene)

Below is the least expensive EROS B data offered. Prices increase for new collections and data processing. Note that academic and volume discounts are available.

For an exact quote, please contact our Sales Team at sales@apollomapping.com.
