GEOSAT-2 Satellite

GEOSAT-2 satellite offers high-quality 75-cm satellite imagery with four multispectral bands.

GEOSAT-2 Satellite Imagery Samples

1-deimos-2
GEOSAT-2 75-cm Natural Color – Madrid, Spain; September 23, 2016
2-deimos-2
GEOSAT-2 75-cm Natural Color – Madrid, Spain; September 23, 2016
3-deimos-2
GEOSAT-2 75-cm Natural Color – Madrid, Spain; September 23, 2016
4-deimos-2
GEOSAT-2 75-cm Natural Color – Madrid, Spain; September 23, 2016
5-deimos-2
GEOSAT-2 75-cm Natural Color – Boulder, Colorado, USA; November 22, 2015
6-deimos-2
GEOSAT-2 75-cm Natural Color – Boulder, Colorado, USA; November 22, 2015
7-deimos-2
GEOSAT-2 75-cm Natural Color – Manbij, Syria; March 24, 2017

Click on the expand button for a larger view of each image. You can also right-click and save any of the examples to your computer for a full resolution view.

The GEOSAT-2 Advantage

Wide Swath
GEOSAT-2 captures a 12-km swath at 75-cm resolution, making it ideal for larger projects.

Cost Effective
GEOSAT-2 is one of the few satellites with a mid-range resolution better than 1-meter. This makes it a low-cost option while maintaining high quality.
Overview & HistoryGEOSAT-2 SpecificationsPricing

GEOSAT-2 was developed by Elecnor Deimos in Spain and was purchased by GEOSAT in 2021. It offers 1-meter (m) resolution panchromatic imagery along with 4-band, 4-m multispectral (i.e. blue, green, red and near-infrared [NIR]); or 75-centimeter (cm) 4-band pansharpened imagery. The highly agile sensor is able to quickly collect successive images.

75-cm imagery fills a gap in the high-resolution market between expensive, half-meter or better imagery and lower-quality 1-meter or worse imagery. GEOSAT-2 is ideal for larger projects that require the fidelity of high-resolution imagery.

Launch Details
  • Launch Date: June 19, 2014, 19:11:11 UTC
  • Vehicle: Dnepr-1
  • Site: Yasny Cosmodrome, Dombarovsky region, Russia

GEOSAT-2 Components
  • Dimensions: 310 kg
  • Control Systems: series of coarse sun sensors and star trackers
  • Onboard Storage Capacity: 256 gigabytes
  • Ground Communication Systems:
    • Imagery downlink – 160 Mbits per second
  • Optical Sensor Assembly: 5.7-m focal length, 42-cm aperture

Orbit Characteristics
  • Altitude: 590 km
  • Inclination: 98°
  • Direction: sun-synchronous orbit, north to south (across the lit side of Earth)
  • Equatorial Crossing Time: 10:30 local time (approximate; across lit side of Earth)
  • Revisit Frequency:
    • 2 days, global average

Imaging System
  • Spectral Bands:
    • Panchromatic
    • 4-band multispectral (blue, green, red and NIR)
  • Sensor Resolution:
    • At-nadir – 75-cm pansharpened; or 1-m panchromatic & 4-m multispectral
  • Spectral Band Wavelength Range: (in nm)
    • Panchromatic – 560 to 900
    • Blue – 466 to 525
    • Green – 532 to 599
    • Red – 640 to 697
    • NIR – 770 to 892
  • Dynamic Range: 10-bits

Collection Capabilities
  • Footprint Width: 12 km (at nadir)
  • Daily Collection Capacity: 200,000 sq km
  • Georeferenced Horizontal Accuracy: 100-m CE90 (global average; depends on terrain and nadir pointing)

Below is the least expensive, color GEOSAT-2 data offered. Prices increase for new collections and data processing. Note that academic and volume discounts are available.

For an exact quote, please contact our Sales Team at sales@apollomapping.com.

Buy GEOSAT-2 Imagery
